Adding User Defined Type (UDT)

A User-Defined Type (UDT) is a custom data type that allows users to model complex or domain-specific information beyond the default system types (e.g., Integer, String). Types can be used as parameters for stored procedures.

Steps to Add a Type

1. Create the Type

   • In the Explorer menu, right-click the created DB Entity.
   • Select Add Type.

2. Configure Type Properties

   Property	Description	Comments
   Name*	Name of the UDT.	Must start with a character followed by alphanumeric or ''. No spaces or special characters except ''. Max length: 50 characters.
   Is Multipart Formdata	Used to handle file uploads via form submission.	Default: No.
   Is Binary	Indicates whether the UDT stores binary data.	Default: No.
   Is Active	Specifies if the UDT is accessible.	Default: Yes.
   Description	Description of the UDT.	Optional.

3. Click Save.

4. Upon successful creation, the message "Type Added Successfully" appears.

5. The created Type will be visible in the DB Entity folder with a UDT tag.

Add Attributes to a Type

1. Open the Type

   • Right-click on Type Entities.
   • Select 'Add/Update Attribute'.
   • Provide values for attribute properties.

2. Configure Type Attribute Properties

   #	Property	Description
   1	Name	Name of the attribute.
   2	Datatype	Select from: String, Integer, Long, Double, Boolean, DateTime, Binary.
   3	Scale	Number of digits after the decimal (for Double).
   4	Precision	Total number of digits (left and right of decimal, for Double).
   5	Mandatory	Indicates if the attribute is required.
   6	Length	Maximum allowed size for the attribute value.
   7	Date Option	Choose Fixed or Current Date.
   8	Default Value	Sets a default value if none is provided.
   9	Example Option	Provides an example format.
   10	Description	Brief description of the attribute.

3. Save the Type Attributes — Click Save.

Use Case Example

Scenario: Creating a UDT for Address Information

1. Create a UDT called AddressType.
2. Add Attributes:
   • Street (String, Max Length: 256)
   • City (String, Max Length: 50)
   • State (String, Max Length: 50)
   • PostalCode (String, Max Length: 10)
   • Country (String, Max Length: 50)
3. Use AddressType in a Customer entity for managing customer addresses.
